Note: HDTV is HDMI, they are the same meaning, just different words.

• 4K Video Capture: Experience superior video recording with the HD 4K Video Capture Card, ensuring every detail is captured in stunning clarity.

• USB3.0 2.0 HDTV Support: Enjoy seamless connectivity with USB3.0 2.0 HDTV support, allowing for easy recording from a wide range of devices.

• Versatile Recording: Perfect for PS4 game recording, DVD camcorder recording, and live streaming, this capture card offers versatility for all your recording needs.

• Compact Design: Its compact design makes it easy to carry and use, perfect for on-the-go creators and content creators.

• High Compatibility: This external capture card boasts high compatibility, making it a reliable choice for various devices.

• Easy Setup: With its user-friendly design, setting up and starting your recordings is a breeze, saving you time and effort.

Description: USB3.0 USB2.0 Audio Video Capture Card HDTV To USB 3.0 2.0 Acquisition Card Live Streaming Plate Camera Switch Game Recording video capture can capture both HDTV video and HDTV audio, sending audio and video signals to computers and smart phones for preview and storage. Suitable for high definition acquisition, teaching recording, medical imaging, etc.

Feature:

* Support input max resolution 3840×2160@30Hz;

* Support output max resolution 1920×1080@30Hz/60Hz;

* Support 8/10/12bit deep color;* Support AWG26 HDMI standard cable: input up to 15 meters, (1080P and below resolution);

* Support most acquisition software, such as VLC、OBS 、Amcap, etc;

* Support for Windows、Android and MacOS;* Conform to USB Video and for UVC standard;

* Conform to USB Audio for UAC standard;

* Without an external power supply, it is compact and portable.

Specifications:

HDTV resolution: Max input can be 3840×2160@30Hz

Support video format: 8/10/12bit Deep color

Video output format:YUV、JPEG

Video output resolution: Max output can be 1920×1080@30Hz/60Hz

Support audio format: L-PCMInput cable distance: ≤15m, AWG26 HDTV standard cable

Max working current: 0.4A/5VDC

Connection and Operation

1: Connect the UHD signal source to the HDTV input of the video capture with one HDTV cable.

2: Connect the computer to the USB port of the video capture with a USB cable.

3: Operation steps for USB video capture(OBS): Open the software→Choose sources of“Video capture Device”→Set the size of image→Choose “Studio Mode”(double window)→Choose “Start Recording”.Operation Example as below

1. Add new sources, choose “Nsendato Video Capture Device ”
